Weintek MT8070iE HMI
Manufacturer: Weintek

The new iE series of operator panels, made by Weintek, is one that follows the MT6000 and MT8000 series panels. It features a highly flexible customized exterior design, easy installation in embedded application, and dust and water proof flat cabinet. The iE Series offers a widescreen, full-color TFT screen with a diagonal of 7″, an LED back light, and touch screen controls. The high resolution screen can depict detailed visualizations of technological processes. Configuration is done via our software: Easy Builder Pro.

More+
Features Model
  • 7″ 800 x 480 TFT LCD, LED backlight.
  • Front surface is flush with the control box.
  • Easy to clean, anti dirt-collecting edges and corners.
  • Selectable mounting holes that match different panel thicknesses.
  • PCB coating process ensures high reliability to resist corrosion in harsh environments.
  • Com1 / Com3 RS485 dual isolation design ensures reliable operation in complex grounding application.
  • Fan-less Cooling System
  • COM1 and COM3 [RS485] 2W support MPI
Mfr. Part No. Description
MT8070iE Resolution, 800x480
