Get the very best out of your basic applications
ACS150 variable frequency drives feature an integrated control panel with LCD display and built-in potentiometer. For easy setup and commissioning, the drives include a variety of pre-defined I/O configuration macros, including: ABB standard, 3-wire control, digital input control, PID control, Hand/Auto control, and a PLC interface. User defined macros can also be created.
The ACS150 drive has an extensive list of programmable drive parameters to achieve high performance with maximum versatility in many applications.
FlashDrop, an optional drive confi guration tool, can be used to quickly and easily confi gure spares or large volumes of unpowered drives using the connection port on the front panel. FlashDrop stores up to 20 different parameter sets and can copy parameters from on drive to another, or between a PC and a drive
The ACS150 can be used on a wide range of machinery including conveyors, pumps, fans, as well as many food and beverage and material handling applications. Its compact size makes it a great option to replace existing starters and contactors while creating energy savings.
| Mfr. Part No. | Description |
| ACS150-01U-02A4-2 | 0.5 HP @ 150% Overload; IP20 Protected Chassis;1-Ph=200v, 208v, 230v, 240v;9.41(h) X 2.76(w) X 5.59(d);Frame Size: R0; Weight: 34.8oz |
| ACS150-01U-04A7-2 | IP20 Protected Chassis; 1-Ph=200v, 208v, 230v, 240v;9.41(h) X 2.76(w) X 5.59(d); Frame Size: R1;Weight: 46.4oz |
| ACS150-01U-06A7-2 | 1-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 5.59(d); Frame Size: R1;Weight: 46.4oz |
| ACS150-01U-07A5-2 | 1-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 5.59(d);Frame Size: R2; Weight: 52.8oz |
| ACS150-01U-09A8-2 | 3 HP @ 150% Overload; IP20 Protected Chassis;1-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 6.34(d);Frame Size: R2;Weight: 52.8oz |
| ACS150-03U-02A4-2 | IP20 Protected Chassis; 3-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 5.59(d); Frame Size: R0; Weight: 38.4oz |
| ACS150-03U-03A5-2 | IP20 Protected Chassis; ;3-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 5.59(d);Frame Size: R0;Weight: 38.4oz |
| ACS150-03U-04A7-2 | 3-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 5.59(d); Frame Size: R1; Weight: 46.4oz |
| ACS150-03U-06A7-2 | 9.41(h) X 2.76(w) X 5.59(d); Frame Size: R1; Weight: 46.4oz |
| ACS150-03U-07A5-2 | 3-Ph=200v, 208v, 230v, 240v; 9.41(h) X 2.76(w) X 5.59(d); Frame Size: R1; Weight: 46.4oz |
| ACS150-03U-09A8-2 | 3-Ph=200v, 208v, 230v, 240v;9.41(h) X 2.76(w) X 6.34(d);Frame Size: R2;Weight: 52.8oz |
| ACS150-03U-01A2-4 | 3-Ph=380v, 400v, 415v, 440v, 480v; 9.41(h) X 2.76(w) X 5.59(d);Frame Size: R0;Weight: 38.4oz |
| ACS150-03U-01A9-4 | 3-Ph=380v, 400v, 415v, 440v, 480v;9.41(h) X 2.76(w) X 5.59(d); Weight: 38.4oz |
| ACS150-03U-02A4-4 | IP20 Protected Chassis; 3-Ph=380v, 400v, 415v, 440v, 480v; 9.41(h) X 2.76(w) X 5.59(d) |
| ACS150-03U-03A3-4 | 1.5 HP @ 150% Overload; IP20 Protected Chassis; 3-Ph=380v, 400v, 415v, 440v, 480v; 9.41(h) X 2.76(w) X 5.59(d) |
| ACS150-03U-04A1-4 | 2 HP @ 150% Overload;IP20 Protected Chassis;3-Ph=380v, 400v, 415v, 440v, 480v;9.41(h) X 2.76(w) X 5.59(d) |
| ACS150-03U-05A6-4 | 3-Ph=380v, 400v, 415v, 440v, 480v; 9.41(h) X 2.76(w) X 5.59(d);Frame Size: R1;Weight: 46.4oz |
| ACS150-03U-08A8-4 | 3-Ph=380v, 400v, 415v, 440v, 480v; 9.41(h) X 2.76(w) X 5.59(d); Frame Size: R1; Weight: 46.4oz |
