Schneider Electric Altivar 12 Variable Speed Drive

share
Schneider Electric Altivar 12 Variable Speed Drive
Manufacturer: Schneider

The Altivar 12 drive is a frequency inverter for three-phase 200…240 V asynchronous motors rated from 0.18 kW/0.25 HP to 4 kW/5 HP.

The Altivar 12's ease of installation, based on the principle of Plug&Play, its compact size, its integrated functions and its alternative base plate version make it particularly suitable for applications involving simple industrial machines and certain consumer machines.

By taking account of the constraints governing installation and use at the product design stage, we have been able to offer a cost-effective solution to manufacturers of compact simple machines (OEMs) and installers.

More+
Features Applications Model Document
  • Can be configured in its packaging
  • Quick start option requiring no adjustment
  • Intuitive navigation
  • Even more compact
  • Category 1 EMC filter
  • Local control on the front panel
  • Modbus serial link
  • Resistant to harsh operating environments
  • A design focussed on integration
  • No compromise on quality
  • Save time on wiring, programming and commissioning
  • The Altivar 12 is well-suited for use in applications involving simple industrial machines or certain consumer machines. Its compact size, high performance and discreet appearance make it particularly attractive for use in the following sectors:
  • Food industry (ventilation of catering kitchens, bagging machines,bakers’ kneading machines, greenhouses, etc.)
  • Small handling applications (car washes, conveyors, etc.)
  • Medical and health sector (medical beds, fitness machines)
  • Machines with a single-phase socket (wood-working machines,surface polishing and cleaning machines, swimming pool or irrigation pumps, hydromassage bathtubs, etc.)
  • New markets (solar applications, etc.)
  • Simple mechanical applications (2-speed motors, DC motors, mechanical drives, etc.)
Mfr. Part No. Description
ATV12H018F1 ATV12 - 0.18kW - 0.25hp - 100..120V - 1ph
ATV12H018M2 ATV12 - 0.18kW - 0.25hp - 200..240V - 1ph
ATV12H018M3 ATV12 - 0.18kW - 0.25hp - 200..240V - 3ph
ATV12H037F1 ATV12 - 0.37kW - 0.55hp - 100..120V - 1ph - with heat sink
ATV12H037M2 ATV12 - 0.37kW - 0.55hp - 200..240V - 1ph - with heat sink
ATV12H037M3 ATV12 - 0.37kW - 0.55hp - 200..240V - 3ph - with heat sink
ATV12H055M2 ATV12 - 0.55kW - 0.75hp - 200..240V - 1ph - with heat sink
ATV12H075F1 ATV12 - 0.75kW - 1hp - 100..120V - 1ph - with heat sink
ATV12H075M2 ATV12 - 0.75kW - 1hp - 200..240V - 1ph - with heat sink
ATV12H075M3 ATV12 - 0.75kW - 1hp - 200..240V - 3ph - with heat sink
ATV12HU15M2 ATV12 - 1.5kW - 2hp - 200..240V - 1ph - with heat sink
ATV12HU15M3 ATV12 - 1.5kW - 2hp - 200..240V - 3ph - with heat sink
ATV12HU22M2 ATV12 - 2.2kW - 3hp - 200..240V - 1ph - with heat sink
ATV12HU22M3 ATV12 - 2.2kW - 3hp - 200..240V - 3ph - with heat sink
ATV12HU30M3 ATV12 - 3kW - 200..240V - 3ph - with heat sink
ATV12HU40M3 ATV12 - 4kW - 5hp - 200..240V - 3ph - with heat sink
ATV12H018M2TQ ATV12 - 0.18kW - 0.25hp - 200..240V - 1ph - lot of 14
ATV12H037M2TQ ATV12 -0.37kW -0.55hp -200..240V-1ph- w heat sink-lot of 14
ATV12H055M2TQ ATV12 -0.55kW -0.75hp -200..240V -1ph -w heat sink-lot of 14
ATV12H075M2TQ ATV12 - 0.75kW -1hp -200..240V -1ph -w heat sink-lot of 14
