Siemens Sinamics G120C Compact Vector Standard AC Drive

Siemens Sinamics G120C Compact Vector Standard AC Drive
Manufacturer: Siemens

SINAMICS G120C has been specially designed for machine manufacturers looking for an economic, space-saving and easy-to-operate standard AC drive providing a surprisingly wide range of functions. This device combines compactness with superior power density and is characterized by fast installation and commissioning, user-friendly connections, and easy-to-use operating tools.

With its three frame sizes, the SINAMICS G120C covers a performance range of 0.75 to 25 HP (0.55 to 18.5 kW). The energy-efficient device serves the most common communication interfaces and is an integral part of Totally Integrated Automation.

Features Applications Model Document
  • Smallest Size

    - Compact, small drive, high power density

    - Quick mechanical installation (i.e. pluggable terminals)

    - Side-by-side mounting without derating

  • Ease of Use

    - Simple, optimized commissioning

    - Effective, adequate parameter set (simple storing and cloning)

    - Usable with IOP, BOP-2 panels and USB connection

  • Leading-Edge Technology

    - Energy-efficient, encoderless vector control - automatic flow reduction with V/Hz ECO

    - Safety (STO) included at no additional cost

    - Profibus, CAN, Modbus RTU, and USS available

  • Machine building edit test
  • Mixers
  • Conveyors
  • Fans
  • Pumps
  • Compressors
  • Basic production machines
Mfr. Part No. Description
G120C 380 - 480V 3-ph ± 10%, 0.75 to 25 HP (0.55 – 18.5kW), V/Hz, Vector
