Siemens Robicon W150CP 18-pulse clean power enclosed drive
Manufacturer: Siemens

A result of the powerful combination of SINAMICS®, the most advanced drives technology platform, and the ROBICON legacy of more than 20 years of quality and expertise in the water and waste water industry, the W150CP makes the best even better.

The compact and quiet ROBICON W150CP utilizes the well proven, simple yet effective, 18-pulse technologyto provide clean power to meet the low harmonic requirements of IEEE 519-1992 at the VFD input terminals, combined with a state-of- the-art power module with IGBT power semiconductors. The drive can be operated in either Volts/Hertz, sensorless vector, or closed loop vector with encoder control modes.

More+
Features Model Document

The standard drive enclosure is a floor standing cabinet, which can be equipped with a wide variety of pre-engineered and custom options. The ROBICON W120CP has the following standard features:

  • NEMA 1 enclosure, with blowers (optional NEMA 12 ventilated with air filters)
  • Circuit breaker disconnect with flange mount operator handle, mechanically interlocked with the enclosure door
  • Short circuit current rating (SCCR) 65 kA at 480 VAC
  • Clean power 18-pulse front end with patented phase shifting autotransformer and input line reactor
  • Motor side IGBT inverter with pulse width modulated (PWM) output featuring pulse edge modulation (PEM) and optimized pulse patterns
  • Advanced operator panel (AOP30), door mounted for easystart-up and operation
  • UL listing per UL508C
  • Windows based STARTER software – common to all modelsof the SINAMICS family
Mfr. Part No. Description
W150CP 3AC 460 - 480V, 60 Hz, 250 - 600 HP (185 - 450 kW)
