Square D 7RT General Purpose Current Transformer

share
Square D 7RT General Purpose Current Transformer
Manufacturer: Schneider

Mounting bracket MB-1 is for use with Model 5NR current transformer. The MB-1 bracket may also be applied to the Model 2NR, if bracket is required. Removable mounting ears are supplied on Model 54R only.

More+
Features Model
  • These low cost, compact units offer good electrical performance in a general purpose transformer.
  • UL and CUL Listed per Classification XODW2.
  • Feature permanent polarity marks molded into the case.
  • All models include two #16 AWG, 24" long secondary leads (white polarity X1 lead).
  • Frequency: 50-400 Hz.
  • Insulation: 10 kV BIL Full Wave (600 Volt class).
  • Applicable Standard: ANSI C57.13.
  • Mounts easily on the conductor. No mounting bracketsnecessary. Optional mounting brackets are available and shipped unassembled.
  • Model 54R features mounting ears molded into the case for easy installation.
  • Model 7RL is are designed for applications used with ammeters, wattmeters, small relays, and cross current compensation. Optional terminals are available. Order as 7RT.
Mfr. Part No. Description
7RT-500 Current Rating (Amperes), 50:5
7RT-101 Current Rating (Amperes), 100:5
7RT-151 Current Rating (Amperes), 150:5
7RT-201 Current Rating (Amperes), 200:5
7RT-251 Current Rating (Amperes), 250:5
7RT-301 Current Rating (Amperes), 300:5
7RT-401 Current Rating (Amperes), 400:5
7RT-501 Current Rating (Amperes), 500:5
7RT-601 Current Rating (Amperes), 600:5
7RT-751 Current Rating (Amperes), 750:5
7RT-801 Current Rating (Amperes), 800:5
7RT-102 Current Rating (Amperes), 1000:5
7RT-122 Current Rating (Amperes), 1200:5
7RT-152 Current Rating (Amperes), 1500:5
7RT-151-001 Current Rating (Amperes), 150:1
7RT-251-001 Current Rating (Amperes), 250:1
7RT-301-001 Current Rating (Amperes), 300:1
7RT-401-001 Current Rating (Amperes), 400:1
7RT-501-001 Current Rating (Amperes), 500:1
7RT-601-001 Current Rating (Amperes), 600:1
