Home → Frequency Converter → Schneider Electric Altivar 212 Variable Speed Drive

Schneider Electric Altivar 212 Variable Speed Drive

share
Schneider Electric Altivar 212 Variable Speed Drive
Manufacturer: Schneider

The Altivar 212 is a variable speed drive for 3-phase asynchronous motors from 0.75 kW to 75 kW. It is specifically intended for the most commonly encountered fluid management applications in tertiary sector buildings (HVAC): heating, ventilation, air conditioning and pumping. Due to its eco-energy based design, energy savings of up to 70% can be achieved compared to a traditional control system.

The Altivar 212 is operational from the moment the power is turned on; it can be used to achieve your building's maximum energy efficiency.

More+
Features Applications Model Document
  • Instant viewing of the energy consumption.
  • Detection of failures for quick intervention: belt breakage, pump running dry, phase failure, supply fault, etc.
  • Preventative maintenance for reducing costs and optimising the equipment: fault alert, operating time, etc.
  • Connection to building supervision network using embedded protocols.
  • Transient over torque: 110% - 60 s.
  • Integrated EMC filters, categories C1 to C3 depending on model
  • Communication bus most commonly used on the market integrated: Modbus, METASYS N2®, APOGEE FLN P1® and BACnet®. Optional: LonWorks
  • Complies to international standards and certifications: UL, CSA, C-Tick and NOM
  • Antiharmonic technology enables a THDI < 30% to be achieved

The Altivar 212 has been designed for the most common fluid management applications in buildings the service sector:

  • Ventilation
  • Heating and air conditioning
  • Pumping
Mfr. Part No. Description
ATV212HD11M3X ATV212 - 11kW - 15hp - 240V - 3ph -wo EMC - IP21
ATV212H075N4 ATV212 - 0.75kW - 1hp - 480V - 3ph - EMC - IP21
ATV212HD11N4 ATV212 - 11kW - 15hp - 480V - 3ph - EMC - IP21
ATV212HD15M3X ATV212 - 15kW - 20hp - 240V - 3 ph - wo EMC - IP21
ATV212HD15N4 ATV212 - 15kW - 20hp - 480V - 3ph - EMC - IP21
ATV212HD18M3X ATV212 - 18.5kW - 25hp - 240V - 3 ph - wo EMC - IP21
ATV212HD18N4 ATV212 - 18.5kW - 25hp - 480V - 3ph - EMC - IP21
ATV212HD22M3X ATV212 - 22kW - 30hp - 240V - 3ph - wo EMC - IP21
ATV212HD22N4 ATV212 - 22kW - 30hp - 480V - 3ph - EMC - IP21
ATV212HD22N4S ATV212 - 22kW - 30hp - 480V - 3ph - EMC - IP21
ATV212HD30M3X ATV212 - 30kW - 40hp - 240V - 3ph - wo EMC - IP21
ATV212HD30N4 ATV212 - 30kW - 40hp - 480V - 3ph - EMC - IP21
ATV212HD37N4 ATV212 - 37kW - 50hp - 480V - 3ph - EMC - IP21
ATV212HD45N4 ATV212 - 45kW - 60hp - 480V - 3ph - EMC - IP21
ATV212HD55N4 ATV212 - 55kW - 75hp - 480V - 3ph - EMC - IP21
ATV212HD75N4 ATV212 - 75kW - 100hp - 480V - 3ph - EMC - IP21
ATV212HU15M3X ATV212 - 1.5kW - 1.5hp - 240V - 3ph - wo EMC - IP21
ATV212HU15N4 ATV212 - 1.5kW - 2hp - 480V - 3ph - EMC - IP21
ATV212HU22M3X ATV212 - 2.2kW - 3hp - 240V - 3ph - wo EMC - IP21
ATV212HU22N4 ATV212 - 2.2kW - 3hp - 480V - 3ph - EMC - IP21
