Schneider Electric Altivar 312 Variable Speed Drive

Manufacturer: Schneider

The Altivar 312 drive is a frequency inverter for 200...600 V three-phase asynchronous motors from 0.18 to 15 kW. The Altivar 312 drive is robust, compact and easy to install. Its integrated functions are particularly suitable for the requirements of applications involving simple industrial machines.

By taking account of constraints on product setup and use right from the design stage, we are able to offer a reliable, cost-effective solution to manufacturers of simple machines and installers.

With its various communication cards that are available as options, the Altivar 312 drive integrates perfectly in the main control system architectures.

More+

Features Applications Model Document

The Altivar 312 drive has six logic inputs, three analog inputs, one logic/analog
output and two relay outputs.
The main functions available are as follows:
Motor and drive protection
Linear, S, U or customized acceleration and deceleration ramps
Local control of the speed reference using the navigation button
+/- speed
16 preset speeds
PI regulator and references
2-wire/3-wire control
Brake sequence
Automatic catching a spinning load with speed detection and automatic restart
Fault configuration and stop type configuration
Saving the configuration in the drive
Several functions can be assigned to one logic input

Handling and packing
Packaging
Textile machines
Special machines
Pumps and fans

Mfr. Part No.	Description
ATV312H018M2	ATV312 - 0.18kW - 0.6kVA - 24W - 200..240 V- 1-phase supply
ATV312H018M3	ATV312 - 0.18kW - 0.7kVA - 23W - 200..240 V- 3-phase supply
ATV312H037M2	ATV312 - 0.37kW - 1kVA - 41 W - 200..240 V - 1-phase supply
ATV312H037M3	ATV312 - 0.37kW - 1.3kVA - 38W - 200..240 V- 3-phase supply
ATV312H037N4	ATV312 - 0.37kW - 1.5kVA - 32W - 380..500 V- 3-phase supply
ATV312H055M2	ATV312 - 0.55kW - 1.4kVA - 46W - 200..240 V- 1-phase supply
ATV312H055M3	ATV312 - 0.55kW - 1.7kVA - 43W - 200..240 V- 3-phase supply
ATV312H055N4	ATV312 - 0.55kW - 1.8kVA - 37W - 380..500 V- 3-phase supply
ATV312H075M2	ATV312 - 0.75kW - 1.8kVA - 60W - 200..240 V- 1-phase supply
ATV312H075M3	ATV312 - 0.75kW - 2.2kVA - 55W - 200..240 V- 3-phase supply
ATV312H075N4	ATV312 - 0.75kW - 2.4kVA - 41W - 380..500 V- 3-phase supply
ATV312H075S6	ATV312 - 0.75kW - 2.5kVA - 36W - 525..600 V- 3-phase supply
ATV312HD11M3	ATV312 - 11kW - 22kVA - 477 W - 200..240 V - 3-phase supply
ATV312HD11N4	ATV312 - 11kW - 25kVA - 397 W - 380..500 V - 3-phase supply
ATV312HD11S6	ATV312 - 11kW - 25kVA - 257 W - 525..600 V - 3-phase supply
ATV312HD15M3	ATV312 - 15kW - 28.5kVA - 628W - 200..240 V- 3-phase supply
ATV312HD15N4	ATV312 - 15kW - 32kVA - 492 W - 380..500 V - 3-phase supply
ATV312HD15S6	ATV312 - 15kW - 33kVA - 335 W - 525..600 V - 3-phase supply
ATV312HU11M2	ATV312 - 1.1kW - 2.4kVA - 74W - 200..240 V- 1-phase supply
ATV312HU11M3	ATV312 - 1.1kW - 3kVA - 71 W - 200..240 V - 3-phase supply
