Keyence PZ-G series Built-in amplifier photoelectric sensor

Manufacturer: Keyence

High-power, dual LED-type photoelectric sensors for improved performance and ease of use.

More+

Features Model

Reflective, Retro-Reflective and Thrubeam (breakbeam) types are all available in the PZ-G Series. These sensors have the power to blast over 130 ft and the sensitivity to detect even clear targets.
Simple trimpot calibration and light-on/dark-on capabilities are built into each PZ-G. Additional features like built-in alignment indicators make the PZ-G series very easy to use.
One touch brackets and optional M8 & M12 quick disconnects save considerable time during the installation process or replacement.

Mfr. Part No.	Description
PZ-G101B	Threaded mount Reflective Cable Type, NPN, 200 mm
PZ-G102CB	Threaded mount Reflective M12 Connector Type, NPN, 5 to 45 mm
PZ-G41CN	Square Reflective M8 Connector Type, NPN, 1 m
PZ-G42CP	Square Reflective M8 Connector Type, PNP, 300 mm
PZ-G51EN	Square Transmissive M12 Connector Type with Cable, NPN, 20 m
PZ-G52EP	Square Transmissive M12 Connector Type with Cable, PNP, 40 m
PZ-G61N	Square retro-reflective Cable Type, NPN, 0.1 to 4.2 m
PZ-G62P	Square retro-reflective Cable Type, PNP, 0.1 to 1 m
