TYCO Model BFV-300,BFV-300C Butterfly Valve, Grooved End
Manufacturer: TYCO

The BFV-300, BFV-300C combines unique new features into our best butterfly valve yet. Its more compact size means greater flexibility for connection locations. Its smarter, simpler design means more efficient installation, easier operation and long-term performance.

More+
Features Applications Model Document
  • Indicating type valves provide visual indication of whether the valve is open or closed
  • Cut groove inlet and outlet connections
  • Suitable for use with grooved pipe couplings that are listed or approved for fire protection service
  • Rated for use at a maximum pressure of 300 psi (20,7 bar), or 175 psi (12,0 bar) for the 10" model
  • Listings and Approvals: UL, C-UL, FM, Calif. State Fire Marshall

For applications requiring supervision of the open position of the valve, the Gear Operators for the Model BFV-300, BFV-300C Butterfly Valves are provided with two sets of factory installed internal switches each having SPDT contacts. The supervisory switches transfer their electrical contacts when there is movement from the Valve’s normal open position during the first two revolutions of the handwheel.
