Siemens SM1226 Fail-safe Digital Output Module

share
Siemens SM1226 Fail-safe Digital Output Module
Manufacturer: Siemens

Digital outputs as a supplement to the integral I/O of the CPUs

Integrated into the overall automation for the implementation of safety-related requirements

With integrated safety functions

Communication with fail-safe CPUs via PROFIsafe mechanisms

For flexible adaptation of the controller to the corresponding task

For subsequent expansion of the system with additional outputs

Operable exclusively in the central system

More+
Features Applications Model
  • 4 outputs, current sourcing/sinking
  • Certified up to SIL 3 (IEC 61508), PL e (ISO 13849)
  • Output current 2 A
  • Rated load voltage 24 V DC
  • Suitable for solenoid valves, DC contactors and indicator LEDs
  • Module fault indicator (DIAG; green and red LED)
  • Status indicator for each output (green LED)
  • Fault indicator for each output (red LED)
  • Plain text identification of module type and function class:
  • 2D matrix code (article and serial number)
  • Color coding of the module type DI: White
  • Hardware and firmware version
  • Complete article No.
  • The fail-safe modules of the SIMATIC S7-1200 permit the implementation of safety-related application requirements integrated into the overall automation. The safety functions required for fail-safe operation are integrated in the modules. Communication with the failsafe SIMATIC S7 CPUs is performed by means of PROFIsafe mechanisms.
  • The modules can be operated exclusively in the central system.
Mfr. Part No. Description
6ES7226-6DA32-0XB0 DIGITAL OUTPUT SM 1226, F-DQ 4X 24VDC
