Siemens CP440 Module

Manufacturer: Siemens

For connection to third-party systems with simple communication protocols, such as protocols with start and end characters or protocols with block-check characters. The interface's handshake signals can be scanned and controlled via the user program.

For connection to Siemens devices or third-party devices by means of the standardized and published Siemens 3964 (R) protocol. Also implemented are a 3964(R) driver with default values and a programmable 3964(R) driver.

More+

Features Applications Model

For high-performance transmission of messages via point-to-point connections (high message rate)
Physical interface: RS 422/RS 485 (X.27)
Up to 32 nodes
Protocol implemented: ASCII, 3964 (R)
Simple parameterization via a parameterization tool integrated into STEP 7

SIMATIC S7, SIMATIC S5 programmable logic controllers and third-party controllers
Programming devices and PCs
Robot controls
Scanners, barcode readers
Measuring systems
Scales

Mfr. Part No.	Description
6ES7440-1CS00-0YE0	CP 440-1, PTP-CONNECTIONS, 1 CHANNEL
