Butterfly Valve
→
Siemens Butterfly Valves PN 6-10-16 for flanged connection
Siemens Butterfly Valves PN 6-10-16 for flanged connection
share
Manufacturer:
Siemens
More+
Features
Applications
Model
Document
Grey cast iron housing EN-GJL-250 (to DN 300) nodular cast iron housing EN-GJS-400-15 (from DN 350)
DN 40…600
kvs 50…29300 m3/h
For fitting between PN 6, PN 10, PN 16 counter-flanges to ISO 7005
Tight-closing in accordance with EN 12266-1, leakage rate A
No maintenance required
Optional ASK46.. manual adjuster (to DN 400)
Optionally equipped with electromotoric actuators SAL.. or SQL36E..
For use as motorized or manual control or shut-off valves in heating, ventilation and air conditioning systems.
In open and closed circuits
For 2-position controls (open/closed)
For 3-position controls
For boiler, chiller and cooling tower sequencing circuits
To open or close the flow to a heat exchanger or to complete plant sections
