Nibco 100PSI WD-L100 Ductile Iron, Wafer Type Actuated, Butterfly Valve
Manufacturer: Nibco

The NIBCO® ductile iron butterfly valve features a unique molded-in Buna-N seat liner with aluminum bronze disc, recommended for most water applications. With the internal stem/disc geometric drive design there is no need for pins or bolts that may create leak paths or turbulence in the waterway. An extended neck allows for insulation up to 2 inches.

More+
Features Applications Model
  • Valve pressure rating 100 psi
  • Maximum 180°F service
  • Wafer style, actuated
  • Buna-N molded-in seat liner
  • Aluminum bronze disc
  • Stainless steel stem with copper bushings
  • Extended neck
  • Geometric drive
  • Operating mechanism: Bare stem for use with pneumatic or electric actuators
  • Not recommended for steam service
  • Conforms to MSS SP-67, MSS SP-25
  • U.S. Coast Guard Category A
  • Size range 2” to 12”

The NIBCO® wafer type butterfly valve is provided with undercut discs for actuation purposes only. The valve is specifically designed for low pressure (100 psi bubble-tight) on/off or modulating applications to be used in conjunction with pneumatic or electric actuators.
