TYCO Model BFV-N Wafer Style 2 to 12 Inch Butterfly Valve
Manufacturer: TYCO

The TYCO Model BFV-N Wafer Style Butterfly Valves are indicating type valves designed for use in fire protection systems where a visual indication is required as to whether the valve is open or closed. They are used, for example, as system, sectional, and pump water control valves. They have cut groove inlet and outlet connections that are suitable for use with grooved end pipe couplings that are listed and approved for fire protection systems.

More+
Features Applications Model Document
  • Indicating type valves provide visual indication of whether the valve is open or closed
  • Wafer connections
  • Suitable for use installation between ANSI Class 125 or 150 flanges without the need for flange gaskets
  • Rated for use at a maximum pressure of 250 psi (17,2 bar)
  • Listings and Approvals: UL, C-UL, FM, Calif. State Fire Marshall

For applications requiring supervision of the open position of the valve, the Gear Operators for the Model BFV-N Wafer Style 2 to 12 Inch Butterfly Valves are provided with two sets of factory installed internal switches each having SPDT contacts. The supervisory switches transfer their electrical contacts when there is movement from the Valve’s normal open position during the first two revolutions of the handwheel.
