Siemens 3G Distribution Dry Type Transformer

share
Siemens 3G Distribution Dry Type Transformer
Manufacturer: Siemens

Distribution Dry Type Transformers

Three Phase

More+
Features Model
  • Actual taps may vary based on volts/turn ratio.
  • Wall designations for units having standard features.
  • Ventilated transformers drip shields are UL listed for outdoor use.
  • Encapsulated transformers are UL listed for indoor/outdoor use.
  • No charge when requested at time of initial project order.
  • If used on unbalanced loads, these auto transformers will need to be used on a 4-wire system with the supply neutral connected to the transformer. If used on motor loads, then they may be used on a 3-wire system without a neutral or fourth wire. Review in NEC 450-4 and 450-5.
  • Items marked floor and wall can be wall mounted with optional wall bracket that may be identified with “W” suffix on catalog number. Wall mounting brackets will not be available for Series J 75kVA with copper winding options.
Mfr. Part No. Description
3G3R003 Temperature Rise, 135° C
3G3R006 Temperature Rise, 135° C
3G3R009 Temperature Rise, 135° C
3G3R015 Temperature Rise, 135° C
3G3Y015D16 Temperature Rise, 150° C
3G3Y030D16 Temperature Rise, 150° C
3G3Y045D16 Temperature Rise, 150° C
3G3Y075D16 Temperature Rise, 150° C
3G3Y112D16 Temperature Rise, 150° C
3G3Y150D16 Temperature Rise, 150° C
3G3Y225D16 Temperature Rise, 150° C
3G3Y300D16 Temperature Rise, 150° C
3G3Y500D16 Temperature Rise, 150° C
3G5R003 Temperature Rise, 135° C
3G5R006 Temperature Rise, 135° C
3G5R009 Temperature Rise, 135° C
3G5R015 Temperature Rise, 135° C
3G5Y015D16 Temperature Rise, 135° C
3G5Y030D16 Temperature Rise, 135° C
3G5Y045D16 Temperature Rise, 135° C
