Sick C4000 Basic Plus Safety Light Curtain

share
Sick C4000 Basic Plus Safety Light Curtain
Manufacturer: Sick

The safety light curtain C4000 Micro, Basic Plus, Basic and Eco are used wherever hazardous points and hazardous areas require reliable and cost effective protection. Cost-efficient: pre-wired "off the shelf" cables M12 x 8 / M12 x 5 and clever accessories like the T-connector for a single home run to the control cabinet save your money. Simplified machine integration due to internal functions like EDM and Restart interlock. Alignment aid and diagnosis via well-proven 7-segment display.

More+
Features Model
  • Type 4 (IEC 61496), PL e (EN ISO 13849)
  • 7-segment display
  • Impact- and scratch-resistant front screen
  • External device monitoring (EDM) and restart interlock (RES)
  • Extremely high electromagnetic immunity
  • Standard M12 connectivity
  • Extensive range of mounting accessories
Mfr. Part No. Description
C40E-0301AG300/C40S-0301AA300 Protective field height 300mm, scanning range 0 m ... 2.5m
C40E-0401AG300/C40S-0401AA300 Protective field height 450mm, scanning range 0 m ... 2.5m
C40E-0601AG300/C40S-0601AA300 Protective field height 600mm, scanning range 0 m ... 2.5m
C40E-0701AG300/C40S-0701AA300 Protective field height 750mm, scanning range 0 m ... 2.5m
C40E-0901AG300/C40S-0901AA300 Protective field height 900mm, scanning range 0 m ... 2.5m
C40E-1001AG300/C40S-1001AA300 Protective field height 1050mm, scanning range 0 m ... 2.5m
C40E-1201AG300/C40S-1201AA300 Protective field height 1200mm, scanning range 0 m ... 2.5m
C40E-1301AG300/C40S-1301AA300 Protective field height 1350mm, scanning range 0 m ... 2.5m
C40E-1501AG300/C40S-1501AA300 Protective field height 1500mm, scanning range 0 m ... 2.5m
C40E-1601AG300/C40S-1601AA300 Protective field height 1650mm, scanning range 0 m ... 2.5m
C40E-1801AG300/C40S-1801AA300 Protective field height 1800mm, scanning range 0 m ... 2.5m
C40E-0303AG300/C40S-0303AA300 Protective field height 300mm, scanning range 0 m ... 6m
C40E-0403AG300/C40S-0403AA300 Protective field height 450mm, scanning range 0 m ... 6m
C40E-0603AG300/C40S-0603AA300 Protective field height 600mm, scanning range 0 m ... 6m
C40E-0703AG300/C40S-0703AA300 Protective field height 750mm, scanning range 0 m ... 6m
C40E-0903AG300/C40S-0903AA300 Protective field height 900mm, scanning range 0 m ... 6m
C40E-1003AG300/C40S-1003AA300 Protective field height 1050mm, scanning range 0 m ... 6m
C40E-1203AG300/C40S-1203AA300 Protective field height 1200mm, scanning range 0 m ... 6m
C40E-1303AG300/C40S-1303AA300 Protective field height 1350mm, scanning range 0 m ... 6m
C40E-1503AG300/C40S-1503AA300 Protective field height 1500mm, scanning range 0 m ... 6m
C40E-1603AG300/C40S-1603AA300 Protective field height 1650mm, scanning range 0 m ... 6m
C40E-1803AG300/C40S-1803AA300 Protective field height 1800mm, scanning range 0 m ... 6m
