Parker P5L-B Cylinder

P5L-B is a base slide for heavy duty linear motion between supports. The max operating presssure is 145 psi. Bore sizes range from 20-100mm. Oversize rod, self-aligning bearing, through hold and T-slot mounting options are available.

The P5L-B series guided cylinder features the popular P1L round body repairable cylinder and offers a fully featured and highly engineered guided bearing system, creating a guided cylinder suitable for the most demanding heavy duty applications. The P5L-B, or ""base"" version, is designed to span the work area and tranlate the load between two support points. Two parallel precision ground case hardened chrome plated, or stainless steel, support shafts are guided by four linear bushings and incorporated into the body assembly. The bearings are prelubricated to provide millions of trouble-free cycles. Composite bushings with standard or oversized shafting or linear ball bearings are available.

The P5L-B Series features a machined, anodized one-piece aluminum body with counterbored through holes and T-slots for mounting flexibility. Standard dowel pin holes provide precision mounting for the body and tool plate. Standard piston wear bands allow the piston rod assembly to ""float"" in the bore thereby eliminating metal-to-metal contact. The result is dramatically greater cylinder seal life especially when the support shafts deflect under load. This ensures very long cylinder life with reduced maintenance and downtime. The P5L-B has a full range of features and options.
