MAC 56 Series Direct pilot operated solenoid valve

Manufacturer: MAC

The MAC 56 Series is a 3-way balanced spool valve piloted by a small direct operated balanced poppet valve. This is an extremely versatile valve: It can be converted for use in vacuum. It can be changed from a Normally Closed function to a Normally Open function by simply rotating a function plate between the pilot and main valve bodies. It can also be converted to a remote air operated valve by removing the solenoid pilot assembly - just to name a few.

Cv (Max): 5.7
Port Sizes: 3/8"-3/4"
Configurations: Individual Inline

More+

Features Model

Balanced spool, immune to variations of pressure.
Short stroke with high flow.
Large spool area provides maximum shifting forces.
Checked accumulator guarantees maximum pilot pressure.
Powerful return force thanks to the combination of mechanical and air springs.
Bonded spool with minimum friction, shifting in a glass-like finished bore.
Wiping effect eliminates sticking.
Pilot valve with balanced poppet, high flow, short and consistent response times.

Mfr. Part No.	Description
56C-12	NC only valve, NC pilot - NC spool, 3/8” NPTF
56C-27	NO only valve, NO pilot - NC spool, 3/4” NPTF
56C-73	NO only valve, NC pilot - NO spool, 1/2” NPTF
