Hohner Series 03 multi-turn analog encoder

Operating temp:

• - 20 ...+ 60 degrees C
• - 4...+ 140 degrees F

Power supply: 24V

Current consumption: 100 mA (max.)

Line driver output max: 50 mA per channel

Weight: 20oz (0.6 kg)

Protection: IP 55 NEMA 3

Housing: Stainless Steel

Shaft: Stainless Steel

Torque: 0.4 oz/in (3 N-cm)

Speed: 300 RPM max.

Vibration: 5g (500 Hz)

Humidity: Up to 98% permissible

Shaft load: Radial / Axial max 10 lbs
