Hammond 850A Audio Broadcast Quality Transformer

Manufacturer: Hammond

Deep-drawn steel case with tin plated finish, with two convenient 6-32 mounting studs with mounting hardware.
Sealed case and wax potted core internally for stable characteristics and long life.
Wide frequency response +/- 0.5 db max. from 20 Hz. to 20 Khz. (except units over 5K ohms impedance, may be down 1 db @ 20 Khz.)
Insertion loss of apx. 1 db.
Maximum power level +15 dbm. with specified characteristics, or higher levels with reduced low frequency performance.
Distortion is apx. 1.5% @ 20 Hz. under full power.
Electrostatic shield between pri. & sec. connected to the green lead.
Humbucking construction
Balanced split windings on pri. & sec. for circuit versatility. Primary may be used as a secondary and vice versa for impedance matching.
Includes mounting hardware.
Lead length: Min. 4"
Shipping weight 0.4 lb. (0.18 kg).

More+

Features Model

Mfr. Part No.	Description
850CA	Nominal Impedance (Ohms), Primary, 12/48
850EA	Nominal Impedance (Ohms), Primary, 50/200
850GA	Nominal Impedance (Ohms), Primary, 150/600
850HA	Nominal Impedance (Ohms), Primary, 150/600
850JA	Nominal Impedance (Ohms), Primary, 150/600
850LA	Nominal Impedance (Ohms), Primary, 5K/20K
850NA	Nominal Impedance (Ohms), Primary, 150/600
850QA	Nominal Impedance (Ohms), Primary, 10K/40K
