ELCO EAM58 CA CANopen Interface Absolute Multiturn Encoder

share
ELCO EAM58 CA CANopen Interface Absolute Multiturn Encoder
Manufacturer: ELCO

CANopen interface absolute multiturn encoder EAM58 series is used in industry environments of special requirements. It delivers good performance in withstanding mechanical damages, and is also capable of withstanding higher axial and radial loads. Various types of flanges can be used to meet the different requirements. It complies with CANopen pertocol and has a max resolution up to 8192 and max revolution up to 4096. The resolution and revolution can be programmed according to customer requirements. Its high speed communication and anti-interference features ensure steady performance during operation.

More+
Features Model Document
  • Clamping flange
  • Pre-screwed holes for the convenience of customers
  • Waterproof seal provides higher IP level
  • Durable stainless steel shaft 6/10
  • Metal housing for better shock resistance
  • Convenient for installation and maintenance open cable output
  • Protection class IP65
  • Conforming to CANopen protocol
Mfr. Part No. Description
EAM58A CA round flange
EAM58B CA synchro flange, shaft length 10mm
EAM58C CA Ф36 clamping flange, shaft length 20mm
EAM58D CA Ф63.5 square flange, Ф31.75, shaft length 20mm
EAM58E CA Ф63.5 square flange, Ф50H7, shaft length 20mm
EAM58W CA shaft length, double-winged spring leaf installation
