Danfoss EV222B Servo-operated 2/2-way solenoid valve
Manufacturer: Danfoss

EV222B is an indirect servo-operated solenoid valve programme for use in connection with contaminated or aggressive media.

Valve body in stainless steel, isolating diaphragm protecting the solenoid system against impurities, build in pilot filter, adjustable closing time, enclosures up to IP67 ensure a reliable and satisfaction function.

More+
Features Model
  • 2/2-way
  • servo-operated
  • isolating diaphragm
  • DN 15 - DN 50
  • Stainless steel valve body
  • NC versions only
  • Differential pressure: Up to 10 bar
  • Viscosity: Up to 50 cSt
  • Ambient temperature: Up to 60 °C
  • Coil enclosure: Up to IP67
  • Isolating diaphragm
  • Water hammer damped
  • Built in filter for protection of pilot system
  • Thread connection: From G ½ – G 2
Mfr. Part No. Description
032U8526 Servo-operated (diaphragm), N C, G 1/2, 15,00 mm, FKM, 0,3 - 10 bar
032U8527 Servo-operated (diaphragm), N C, G 3/4, 20,00 mm, FKM, 0,3 - 10 bar
032U8528 Servo-operated (diaphragm), N C, G 1, 25,00 mm, FKM, 0,3 - 10 bar
032U8529 Servo-operated (diaphragm), N C, G 1 1/4, 32,00 mm, FKM, 0,3 - 10 bar
032U8530 Servo-operated (diaphragm), N C, G 1 1/2, 40,00 mm, FKM, 0,3 - 10 bar
032U8531 Servo-operated (diaphragm), N C, G 2, 50,00 mm, FKM, 0,3 - 10 bar
