Vishay SE20PB/SE20PJ Surface Mount ESD Capability Rectifier
Vishay SE20PB/SE20PJ Surface Mount ESD Capability Rectifier
share
Manufacturer:
Vishay
Case: DO-221AA (SMP)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-M3 - halogen-free, RoHS-compliant, and commercial grade
Base P/NHM3 - halogen-free, RoHS-compliant, and automotive grade
Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102
M3 suffix meets JESD 201 class 1A whisker test, HM3 suffix
meets JESD 201 class 2 whisker test
Polarity: Color band denotes the cathode end
More+
Features
Applications
Model
Very low profile - typical height of 1.0 mm
Ideal for automated placement
Oxide planar chip junction
Low forward voltage drop
ESD capability
Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C
AEC-Q101 qualified
General purpose, power line polarity protection, in both consumer and automotive applications.
