Tamagawa TBL-i mini Series Large-size Servo Motor

share
Tamagawa TBL-i mini Series Large-size Servo Motor
Manufacturer: Tamagawa

A miniature AC servo motor, measuring 14.5,19.5,22mm, has been added to our lineup-making possible via densification the size reduction of products such as semiconductor fabrication equipment, chip mounters, and small XY tables. In order to integrate with a variety of sensors, this AC servo motor is available as either an encoder or resolver.

More+
Features Model
  • Super small motor size.
  • Servo Motor sensors lie-up are resolver type and encoder type
  • Rated output 3,5,10,15W
  • Rated speed 3,000min
  • Maximum speed 6,000min
Mfr. Part No. Description
TS4861N4050E500 Rated torque 0.0095Nm
TS4862N4050E500 Rated torque 0.0159Nm
TS4864N4050E500 Rated torque 0.032Nm
TS4866N4050E500 Rated torque 0.0477Nm
TS4861N2250E500 Peak torque 0.0285Nm
TS4862N2850E500 Peak torque 0.0477Nm
TS4864N2850E500 Peak torque 0.096Nm
TS4866N2850E500 Peak torque 0.1431Nm
TS4871N4050E500 Stoll torque 0.032Nm
TS4872N4050E500 Stoll torque 0.051Nm
TS4873N4050E500 Stoll torque 0.064Nm
TS4875N4050E500 Stoll torque 0.096Nm
TS4631N2050E510 Stoll torque 0.031Nm
TS4632N2050E510 Stoll torque 0.062Nm
TS4633N2050E510 Stoll torque 0.095Nm
