Siemens SIPLUSS7-400CP443-1 Advanced Module

Manufacturer: Siemens

The CP 443-1 Advanced is used to connect the SIMATIC S7-400 to Industrial Ethernet networks. With its own processor, it relieves the CPU of communication tasks and facilitates additional connections.

All the devices of an Ethernet network can be protected from unauthorized access. The CP 443-1 Advanced allows safe remote access over the Internet and allows data transfer between devices or network segments to be protected from data manipulation/espionage.

PROFINET CBA components and security functionalities can be used as an alternative.

More+

Features Applications Model

Cost advantage due to connection to two separate Ethernet segments with integrated network separation
High plant availability through the support of media redundancy (MRP) and use in the SIMATIC S7-400 H system
Optimum support of maintenance through
Web-based diagnostics
Remote programming via WAN or telephone network (ISDN)
Monitoring with IT network management tools (SNMP)
Module replacement without programming device using the C-PLUG swap medium
Securing the system against unauthorized access by means of
Central access protection for any devices within an automation cell, e.g. by means of authentication of the network stations
Secure remote access via the Internet by means of data encryption (VPN) and data integrity checking
Traceability by means of data logging on the basis of standard IT mechanisms (Syslog)
Later connection of existing SIMATIC S7 systems to Industrial Ethernet using the CP 443-1 Advanced ensures investment protection

PGs/PCs
Master computers
HMI systems
SIMATIC S5/S7/C7 systems
PROFINET I/O devices
PROFINET CBA components

Mfr. Part No.	Description
6AG1443-1GX30-4XE0	SIPLUS NET CP443-1 ADVANCED FOR MEDIAL STRESS WITH CONFORMAL COATING BASED ON 6GK7443-1GX30-0XE0 . 1X 10/100/1000 MBIT/S; 4 X 10/100 MBIT/S (IE SWITCH); RJ 45 PORTS; ISO; TCP; UDP; PROFINET-IO CON- TROLLER; S7-COMMUNCATION; OPEN COMMUNICATION (SEND/RE- CEIVE); S7-ROUTING; IP-KONFIGU- RATION VIA DHCP/BLOCK; IP ACCESSS CONTROL LIST; TIME- SYNCHRONISATION; EXTENDED WEB-DIAGNOSIS; FAST STARTUP; PROFIENERGY SUPPORT; IP-ROUTING; FTP; WEB-SERVER; E-MAIL; PROFINET CBA, SECURITY

Mfr. Part No.

Description

6AG1443-1GX30-4XE0

SIPLUS NET CP443-1 ADVANCED FOR MEDIAL STRESS WITH CONFORMAL COATING BASED ON 6GK7443-1GX30-0XE0 . 1X 10/100/1000 MBIT/S; 4 X 10/100 MBIT/S (IE SWITCH); RJ 45 PORTS; ISO; TCP; UDP; PROFINET-IO CON- TROLLER; S7-COMMUNCATION; OPEN COMMUNICATION (SEND/RE- CEIVE); S7-ROUTING; IP-KONFIGU- RATION VIA DHCP/BLOCK; IP ACCESSS CONTROL LIST; TIME- SYNCHRONISATION; EXTENDED WEB-DIAGNOSIS; FAST STARTUP; PROFIENERGY SUPPORT; IP-ROUTING; FTP; WEB-SERVER; E-MAIL; PROFINET CBA, SECURITY
