Siemens CPU1512SPF-1PN CPU Unit

Manufacturer: Siemens

The CPU 1512SP F-1 PN is the CPU for standard and fail-safe applications with medium requirements in terms of processing performance and response speed in discrete production technology. The CPU 1512SP F-1 PN can be used as a PROFINET IO controller or as distributed intelligence (PROFINET I-Device). The integrated PROFINET IO IRT interface is designed as a 3-port switch so that a linear topology can be set up in the system via port 1 and 2, and so that a PG/PC or HMI device can also be connected via port 3.

When used as an I-Device, the CPU 1512SP F-1 PN enables distributed preprocessing of process data locally and only delivers the information actually required to the higher-level controller.

The CPU 1512SP F-1 PN operates completely independently of the central controller. If it fails, the CPU 1512SP F-1 PN simply continues running.

The bit-modular configuration of the ET 200SP I/O system, together with the CPU 1512SP F-1 PN, enables functionally oriented station configuration.

In addition, the CPU offers comprehensive control functionalities via easy-to-configure blocks as well as the ability to connect drives via standardized PLC-open blocks.

More+

Features Applications Model

CPU 1512SP F-1 PN for SIMATIC ET 200SP based on S7-1500 CPU 1513F-1 PN
For applications with medium requirements in terms of program scope and processing speed, for distributed configurations via PROFINET IO or PROFIBUS DP.
Increase in availability of systems and machines
Supports PROFIsafe in centralized and distributed configurations
PROFINET IO controller for up to 128 IO devices
PROFINET I-Device for connecting the CPU as an intelligent PROFINET device with a SIMATIC or third-party PROFINET I/O controller
PROFINET Shared I-Device for 4 controllers
PROFINET IO IRT interface with integrated 3-port switch
Isochronous mode on PROFINET
With multiple communication options:
PG/OP communication, PROFINET IO, open IE communication (TCP, ISO-on-TCP and UDP), Web server and S7 communication (with loadable FBs)
Optional PROFIBUS master for 125 PROFIBUS DP slaves (with CM DP module 6ES7545-5DA00-0AB0)
Configuration control (option handling)
Integrated Motion Control functionalities for controlling speed-controlled and positioning axes, support for external encoders
