Siemens CP343-1 ERPC Module

share
Siemens CP343-1 ERPC Module
Manufacturer: Siemens

The CP 343-1 ERPC (Enterprise Connect) communications processor for connecting a SIMATIC S7-300 to Industrial Ethernet networks.

Connection of the SIMATIC S7-300 to various database systems for vertical integration is supported by means of a firmware expansion from ILS-Technology to be ordered separately.

More+
Features Applications Model
  • Cost reductions through simply configured database connection by means of a firmware extension from the company ILS-Technology, to be ordered separately; no costly programming and no additional gateway PCs
  • Optimum support of maintenance through
  • Web-based diagnostics
  • Remote programming via LAN/WAN (e.g. Internet)
  • Monitoring by network management tools (SNMP)
  • Module exchange without programming device using the C-PLUG swap medium
  • Safeguarding of the system (security) against unauthorized access by means of device-related IP access list (IP-ACL); the capability of later connecting existing SIMATIC S7 systems to Industrial Ethernet using the CP 343-1 Advanced ensures investment protection
  • The capability of later connecting existing SIMATIC S7 systems to Industrial Ethernet using the CP 343-1 ERPC ensures investment protection
  • The CP 343-1 ERPC (Enterprise Connect) is used for connecting the SIMATIC S7-300 to Industrial Ethernet networks and to different ERP or MES systems for vertical integration by means of a firmware extension from the company ILS-Technology, to be ordered separately. With its own processor, the module relieves the CPU of communications tasks and facilitates additional connections.
  • The CP 343-1 ERPC permits communication of the S7-300 with
  • PGs/PCs
  • Master computers
  • HMI devices
  • SIMATIC S5/S7/C7 systems
  • ERP or MES systems by means of database interface, e.g. ORACLE, MySQL, MS-SQL, DB2, SAP by means of a firmware extension from the company ILS-Technology, to be ordered separately
Mfr. Part No. Description
6GK7343-1FX00-0XE0 COMMUNICATIONSPROCESSOR CP343-1 ERPC FOR CONNECTING SIMATIC S7-300 CPU TO INDUSTRIAL ETHERNET AND TO VARIOUS DATABASES. FUNCTIONS: TCP/UDP, S7-COMM, OPEN COMM. WITH AND WITHOUT RFC 1006, MULTICAST, WEBSERVER, TIME VIA SIMATIC PROCESS OR NTP, ACCESS PROTECTION VIA IP-ACCESS LIST, SNMP, DHCP, C-PLUG, GIGABIT-SS 1X RJ45 (10/100/1000 MBIT)
