Onsemi NTSAF545 Trench-based Schottky Rectifier
Onsemi NTSAF545 Trench-based Schottky Rectifier
share
Manufacturer:
Onsemi
Case: Epoxy, Molded
Epoxy Meets Flammability Rating UL 94−0 @ 0.125 in.
Lead Finish: 100% Matte Sn (Tin)
Lead and Mounting Surface Temperature for Soldering Purposes: 260°C Max. for 10 Seconds
Device Meets MSL 1 Requirements
Weight: 95 mg (Approximately)
Cathode Polarity Band
More+
Features
Applications
Model
Fine Lithography Trench−based Schottky Technology for Very Low Forward Voltage and Low Leakage
Fast Switching with Exceptional Temperature Stability
Low Power Loss and Lower Operating Temperature
Higher Efficiency for Achieving Regulatory Compliance
High Surge Capability
These are Pb−Free and Halide−Free Devices
Switching Power Supplies including Tablet Adapters, and Flat Panel Display
High Frequency and DC−DC Converters
Freewheeling and OR−ing diodes
Reverse Battery Protection
Instrumentation
