Onsemi MBRS3201T3G/NRVBS3201T3G200 V 3 A Schottky Fast Soft-Recovery Rectifier
Onsemi MBRS3201T3G/NRVBS3201T3G200 V 3 A Schottky Fast Soft-Recovery Rectifier
share
Manufacturer:
Onsemi
Small Compact Surface Mount Package with J-Bend Leads
Rectangular Package for Automated Handling
Weight: 217 mg (Approximately)
Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable
ESD Ratings: Machine Model = A
Human Body Model = 1C
Lead and Mounting Surface Temperature for Soldering Purposes: 260°C Maximum for 10 Seconds
Polarity: Notch in Plastic Body Indicates Cathode Lead
More+
Features
Applications
Model
Lower Forward Voltage than any Ultrafast Rectifier: VF < 0.59 V at 150°C
Fast Switching Speed: Reverse Recovery Time (tRR) < 35 ns
Soft Recovery Characteristics: Softness Factor (tb/ta) ³ 1
Highly Stable Over Temperature
AEC−Q101 Qualified and PPAP Capable
NRVB Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements
These are Pb−Free Packages
Significantly Reduced EMI
Eliminates the Need of Snubber Circuits
Low Switching and Heat Losses
Improved Thermal Management
Engine and Convenience Control Systems
Motor Controls
Battery Chargers and Switching Power Supplies
