Numatics L1 Series Solenoid Pilot Actuated Valve

Manufacturer: Numatics

The L1 Series air valves offer speed and high flow capacity in a compact design. They are available either with solenoid pilot or air pilot actuation. The L1's slim design (.875" body width) is ideal for inline mounting, while it may also be mounted on one piece extruded manifolds from 2 to 12 stations. A 12 station L1 manifold is only 14.11 inches wide.

More+

Features Model Document

Cv: 1.0
Port Sizes: 1/8, 1/4 NPTF & G
5 ported, 2 and 3 position, 4-way, spool & sleeve
Flow Capacity: 46 SCFM @ 80 PSIG / 985 NI/m @ 6 bar
Main Valve Operating Pressure Range: 28" Hg. Vacuum to 150 PSIG / Vacuum to 10 bar
Pilot Pressure Range (Internal & External): 14.5 to 150 PSIG / 1 to 10 bar
Temperature Range (Ambient):
Solenoid Pilot Actuated: -10°F to +115°F / -23°C to +46°C
Air Pilot Actuated: -10°F to +150°F / -23°C to +66°C
Features:
Solenoid pilot or air pilot actuated
DIN plug-in solenoid and plug connector with indicator light
Unlubricated or lubricated service
In-line or manifold mounted

Mfr. Part No.	Description
L11	Cv: 1; Port Sizes: 1/4 NPTF & G, 5 Ported, 2 and 3 position, 4-way
L12	Cv: 1; Port Sizes: 1/4 NPTF & G, 5 Ported, 2 and 3 position, 4-way
