Hohner Series NAMFPX NAMUR (DIN 19234) encoder

Operating temp:

• - 20 ...+ 60 degrees C
• - 4...+ 140 degrees F

Max frequency: 5 kHz

Current consumption:90 mA (max.)

Power supply:5 - 24V

Weight:53 oz (1.5 kg)

Protection:IP 66M, NEMA 4

Torque:0.8oz/in (6 N-cm)

Humidity:Up to 98% permissible

Speed:Resolution dependant

Vibration:5g (500 Hz)

Line driver output max:50 mA per channel

Max. ppr:512
